How to Setup Kubernetes Cluster with Kubespray

Introduction

Kubespray is open source automation tool to deploy kubernetes cluster, use ansible for deployment kubernetes packages, can use in any environment (on-premise/cloud).

Prerequisites

Linux machine to deploy your kubernetes cluster.

For this tutorial, i want deploy kubernetes cluster with 3 machine, named:

• kube-cp
• kube-node1
• kube-node2

I deploy use deployer machine, you can use your laptop/pc (but makesure the internet connection is reliable with all machine)

Requirements package on deployer/laptop/PC

• Git
• Python
• PIP
• Ansible

Setup Kubespray

Install git on your deployer machine

apt-get install git -y

Clone kubespray repository

https://github.com/kubernetes-sigs/kubespray.git

cd kubespray
git checkout release-2.28

Install requirements package , Use python venv.

apt-get install python3.10-venv -y

python3 -m venv kubespray-venv
source kubespray-venv/bin/activate
pip3 install -r requirements.txt

Copy sample kubespray configuration, i copied as directory cluster-arya

cp -r inventory{sample,cluster-arya}

Add your machine to inventory.ini

vim inventory/cluster-arya/inventory.ini

[kube_control_plane]
arya-cp ansible_host=54.242.81.x ip=172.31.19.230

[etcd:children]
kube_control_plane

[kube_node]
arya-node1 ansible_host=18.234.81.x ip=172.31.19.223
arya-node2 ansible_host=3.90.212.x ip=172.31.17.64

If your machine is under NAT, you need define private machine ip in ip= section

Change other configuration in inventory/cluster-arya/k8s_cluster

inventory/cluster-arya/group_vars/
├── all
│   ├── all.yml
│   ├── aws.yml
│   ├── azure.yml
│   ├── containerd.yml
│   ├── coreos.yml
│   ├── cri-o.yml
│   ├── docker.yml
│   ├── etcd.yml
│   ├── gcp.yml
│   ├── hcloud.yml
│   ├── huaweicloud.yml
│   ├── oci.yml
│   ├── offline.yml
│   ├── openstack.yml
│   ├── upcloud.yml
│   └── vsphere.yml
└── k8s_cluster
    ├── addons.yml
    ├── k8s-cluster.yml
    ├── k8s-net-calico.yml
    ├── k8s-net-cilium.yml
    ├── k8s-net-custom-cni.yml
    ├── k8s-net-flannel.yml
    ├── k8s-net-kube-ovn.yml
    ├── k8s-net-kube-router.yml
    ├── k8s-net-macvlan.yml
    └── kube_control_plane.yml

For example , change network plugin used cilium

vim inventory/cluster-arya/group_vars/k8s_cluster/k8s-cluster.yml

# Choose network plugin (cilium, calico, kube-ovn or flannel. Use cni for generic cni plugin)
# Can also be set to 'cloud', which lets the cloud provider setup appropriate routing
kube_network_plugin: cilium

# Setting multi_networking to true will install Multus: https://github.com/k8snetworkplumbingwg/multus-cni
kube_network_plugin_multus: false

# Kubernetes internal network for services, unused block of space.
kube_service_addresses: 10.233.0.0/18

# internal network. When used, it will assign IP
# addresses from this range to individual pods.
# This network must be unused in your network infrastructure!
kube_pods_subnet: 10.233.64.0/18

Deploy Kubernetes cluster using Kubespray

Run kubespray playbook

ansible-playbook -i inventory/cluster-arya/ cluster.yml -b --user=ubuntu -v --private-key=~/.ssh/id_ed25519

Wait until ansible-playbook finished deploy cluster

PLAY RECAP ************************************************************************************************************************************************
arya-cp                    : ok=561  changed=38   unreachable=0    failed=0    skipped=905  rescued=0    ignored=4
arya-node1                 : ok=467  changed=22   unreachable=0    failed=0    skipped=698  rescued=0    ignored=1
arya-node2                 : ok=423  changed=18   unreachable=0    failed=0    skipped=615  rescued=0    ignored=1

And check kubernetes cluster by accesing control plane machine

root@arya-cp:~# kubectl get nodes
NAME         STATUS   ROLES           AGE   VERSION
arya-cp      Ready    control-plane   32m   v1.33.2
arya-node1   Ready    <none>          31m   v1.33.2
arya-node2   Ready    <none>          31m   v1.33.2

Congrats! You have successfully set up and accessed a kubernetes cluster using kubespray.
